Thông Tin Sản Phẩm

• 16 mic/line inputs with high-headroom Class A XMAX™ mic preamplifiers
• 4 subgroups
• Stereo/mono main out
• 6 auxiliary mixes
• 32-in/18-out FireWire digital recording ­interface (24-bit/44.1 kHz and 48 kHz)
• Studio One Artist Digital Audio Workstation software for Mac® and PC
• Capture™ 1.1 recording software for Mac® and PC
• StudioLive Remote mixer-control software for iPad® available free from Apple App Store
• QMix™ aux-control software for iPhone® and iPod touch® available free from Apple App Store
• Direct recording interface compatible with Logic®, Nuendo, Cubase, Sonar™, Digital Performer™, Ableton™ Live, and more
• 16 channel strips
• Trim control with –20 to +20 dBV line/-15 to +65 dBu mic gain range (80dB!)
• +48V phantom power switch for condenser microphones
• FireWire Input Select
• 100 mm precision faders
• Lighted Solo and Mute buttons
• Access to Fat Channel functions
• 15-LED ladder metering + clip LED
• Analog ¼" insert (rear panel)
• 4 subgroup buses, each with:
  • Solo
  • Mute
  • Access to Fat Channel functions (except high-pass filter and phase reverse)
• 6 aux sends, each with
  • Solo
  • Pre/post-fader send
  • Output-level control
  • Access to Fat Channel functions (except phase reverse)
  • Mix and Mix/Pan Fat Channel metering
  • Available sources:  Channels 1-16, FXA Return, FXB Return
• 2 internal effects sends, each with:
  • Mute
  • Pre/post-fader send
  • Output-level control
  • Access to Fat Channel (except phase reverse)
  • Effects-send Select for Fat Channel metering
  • Mix button for aux-bus mixing and Fat Channel metering
• Master Section
  • Aux Input A and B
  • Level Control and Select (Fat Channel ­metering) switch
  • Access to all Fat Channel functions (except phase reverse)
  • Talkback System
    • Mic Level control
    • Output Select (   Aux 1-2, 3-4, 5-6, Main)
    • Talk button
    • Rear-panel XLR mic input with level control and continuous 48V phantom power
  • 2 Track In
    • Level control
    • Tape Input to Mains button
    • FireWire source on/off
  • Solo Bus
    • Cue Mix volume control
    • PFL/AFL and Solo In Place (SIP) buttons
  • Monitor Bus
    • Headphone-output level control
    • Control-room monitor-level control
    • Solo Bus to Monitor button
    • Tape Input to Monitor button
    • Main L/R FireWire Return to Monitor button
    • Main Mix to Monitor button

• Fat Channel with rotary encoders:2 internal digital effects-processors, each with 50 customizable reverb and delay presets
  • Pan with dedicated 15-LED display
  • Stereo link for input channels, aux buses, and subgroups
  • Phase reverse (main channels only)
  • High-pass filter: 6 dB/oct., sweepable from Off to 1 kHz (main channels and aux's only)
  • 4-band semi-parametric equalization
    • Low EQ: sweepable from 36 Hz to 465 Hz, ±15 dB, switchable shelf or peaking
    • Low Mid EQ: sweepable from 90 Hz to 1.2 kHz, ±15 dB, switchable 0.55/2.0 Q
    • High Mid EQ: sweepable from 380 Hz to 5 kHz, ±15 dB, switchable 0.55/2.0 Q
    • High EQ: sweepable from 1.4 kHz to 18 kHz, ±15 dB, switchable shelf or peaking
  • Gate: Threshold 0 to –84 dB; Rate: 2 to 0.05 sec
  • Compressor: Threshold -56 to 0 dB, Ratio 1:1 to 14:1, Attack 0.2 to 150 ms, Release 40 to 1000 ms, Makeup Gain 0 to 28 dB, Soft Knee switch, Auto Mode with 10 ms Attack and 150 ms Release
  • Limiter: 0 dBFS Threshold, ∞:1 Ratio
  • Output Assign: 4 subgroups and main with post-EQ/post-dynamics option
  • All settings can be copied among channels and saved as user presets.
  • 50 channel-strip presets for drums, bass, guitars, keyboards, and vocals
• 4 dual-mono (eight channels), 31-band graphic equalizers, each assigned to a specific bus: Main Left, Main Right, and Aux 1 through 6
• Scene Store and RecallLockout mode to keep inspired amateurs from changing your settings
  • Global Scene Storage: all current StudioLive settings
    • Up to 80 at a time
  • Automatic Global AutoStore
  • Individual channel-strip Scene storage
    • Up to 48 at a time, plus…
    • 50 factory presets for instruments and vocal
  • Copy and Paste between channels
  • Customizable naming (for example, "Saturday Gig" or "Main Worship Service")
• Metering/Displays
  • 16 x 16- LED Fat Channel matrix:
    • Pre-dynamics/pre-fader input
    • Post-dynamics/post-fader output
    • Gain reduction
    • Aux 1-6 and EFX A/B output
    • Fader-position recall
  • 8 x 15-LED main meter bank
    • Selected channel level
    • Selected channel gain reduction
    • Sub buses 1 to 4
    • Main stereo outputs
  • 15-LED horizontal Pan/Balance display
  • 64 x 194 LCD matrix
    • Effects parameters
    • Scene creation, storage, and recall
    • System menus
  • 2-digit Channel Selected display
• Input/Output
  • 16 main inputs, each with XLR mic, ¼" line, and ¼" inserts
  • 2 ¼" stereo (L/R) aux inputs
  • 1 XLR talkback-mic input with phantom power and level control
  • Unbalanced RCA stereo (L/R) tape inputs and outputs
  • XLR stereo (L/R) main outputs with level control
  • ¼" stereo (L/R) main outputs
  • XLR mono output with level control
  • ¼" stereo (L/R) control-room outputs
  • ¼" Headphone output
  • 4 ¼" subgroup outputs
  • 6  ¼" aux outputs
  • 16 pre-insert, balanced direct outputs, Ch. 1-8 and 9-16 (DB25 sockets)
  • S/PDIF digital out
  • 2 FireWire 400 ports
• Digitalia
  • High-definition analog-to-digital converters (118 dB dynamic range)
  • Unlimited-headroom, 32-bit floating point, digital mixing and effects processing
  • Internal sample frequency 44.1 kHz and 48 kHz
• Physical
  • Rugged, non-flex steel chassis
  • 100 mm long-throw faders
  • Military-grade, quick-touch buttons
  • BNC 12V lamp socket
  • Optional dust covers available
• Software bundle for Mac® and Windows® includes:
  • PreSonus Studio One® Artist digital audio workstation
  • PreSonus Capture™ live-recording software
  • PreSonus Universal Control with Virtual StudioLive™ bidirectional mixer-control software
  • Free downloadable software from the Apple App Store provides wireless remote control, including:
    • PreSonus StudioLive Remote for iPad®
    • PreSonus QMix™ for iPhone® and iPod touch®
